Heavy Duty Concealed Door Bottom Seal 6063 Aluminium Weatherstrips

Brand Name : BHMFT

Model Number : BH-M015A

Certification : CE

Place of Origin : China

MOQ : Negotiable

Price : EXW price US$ 15-25/ set

Payment Terms : T/T

Supply Ability : 1000 sets per week

Delivery Time : 7-10 days after receive the payment

Packaging Details : each one packed by a PE bag, 10 sets in a carton, for length 915mm, carton size: 105*20*10cm, gross weight is about 13kgs per carton.

Shell Materials : 6063 Alumium Alloy

Strips Materials : Silicone Rubber seals

Accessories : 201 Stainless Steel (including side plate and screws)

Type : Concealed type with side edge

Size : 25*44-45mm

Length : can do 650-1500mm

Stock item Length : 800mm, 915mm and 1000mm, other length can do customized

Available Cut Length : 800mm- can cut to 700mm, 915mm- can cut to 800mm, 1000mm- can cut to 900mm

Contact Now

Heavy Duty Automatic Door Bottom Seals Concealed Aluminium Weatherstrips for Fireproof Door Raven RP70 Si

Features:

This item is similar as RAVEN RP70Si, it has the side edge on the bottom, can screw fix it from the door bottom, suitable for the metal door which no need to make the through groove in the door, cannot see any other things except the copper bolt, it is more invisiable. This Heavy Duty design makes it more fit the heavier door, can be used for fireproof door.

Specifications:

Item No.: BH-M015A
Min/Max Gap: 3mm to 15mm
Finish: Clear Anodised
Fixing: Concealed Screw Fix, Fixing holes are pre-slotted
Seal: Grey Silicone Rubber
Fixed Part: Stainless Steel Screws, Nylon side plate
Size can do: 650-1500mm
Regular length: 800mm, 915mm, 1000mm
Regular length can cut length:

800mm - cancut to 700mm,

915mm - can cut to 800mm,

1000mm - can cut to 900mm.

Heavy Duty Concealed Door Bottom Seal 6063 Aluminium WeatherstripsHeavy Duty Concealed Door Bottom Seal 6063 Aluminium WeatherstripsHeavy Duty Concealed Door Bottom Seal 6063 Aluminium WeatherstripsHeavy Duty Concealed Door Bottom Seal 6063 Aluminium Weatherstrips
